D-LINK DGS-712 GIGABIT SFP TO RJ45 TRANSCEIVER
SKU
7111739
$197.59
VIP: $177.72- Buy 2 for $188.18 each and save 5%
D-Link's DGS-712 1000BASE-T Copper Small Form Pluggable (SFP) transceiver is based on the SFP Multi Source Agreement
| Units of Measure | EACH |
|---|---|
| Availability | ETA 3 days |
| Brand | D-LINK |
| Features | Compatible with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE 802.3z and 802.3ab The D-Link DGS-712 plugs into any standard SFP interface allowing for 1000Base-T Gigabit transmission over standard Category 5 twisted pair copper Up to 1.25Gb/s bi-directional data links Hot-pluggable SFP footprint Extended case temperature range Fully metallic enclosure for low EMI Low power dissipation (typical 1.2 watts) RJ-45 connector assembly Access to physical layer IC via 2-wire serial bus 10/100/1000 BASE-T operation in host systems with SGMII interface Gigabit Ethernet over Cat. 5 cable +3.3V electrical power interface Maximum Cable Distance Coverage: 100 meters |
| Standard | IEEE 802.3ab 1000BASE-T Gigabit Ethernet |
|---|---|
| Transceiver Type | SFP (Small Form Pluggable) |
| Connector | RJ-45 |
| Auto MDI/MDIX | Automatic crossover detection enabled, External crossover cable not required |
| Data Rate | 1,000 Mbps (IEEE 802.3 compatible), 10/100/1000 BASE-T operation requires the host system to have an SGMII interface with no clocks. With a SERDES interface, this transceiver will operate at 1000BASE-T only |
| Cable Type | Cat. 5 twisted-pair cable |
| Supply Current | 350mA (typical), 400mA (maximum), 1.3W max power over full range of voltage and temperature |
| Input Voltage | 3.1V (minimum), 3.3V (typical), 3.5V (maximum) |
| Maximum Voltage | 4V |
| Surge Current | 30mA |
| Operating Temperature | 0 to 85 C |
| Storage Temp | -40 to 85 C |
| Warranty | Limited Lifetime |
